日本原装GTR日精减速机型号：GFM-15-5-T90W 380V
苏州上野是GTR日精株式会社中国授权代理商 我司销售产品保证正品，销售电话：178-9504-6997 刘经理 微信同号
基本情報 | 製品名 | |
|---|---|---|
生産情報/代替品情報 | 現行製品 | |
シリーズ | インダクションギアモータ | |
標準価格 | - | |
標準納期[工場出荷日] | - | |
性能値 | 出力軸回転速度 ※モータ同期回転速度を基準 | 300r/min / 50Hz 360r/min / 60Hz |
出力軸許容トルク | 2.06 N・m / 50Hz 2.06 N・m / 60Hz | |
出力軸許容 O.H.L | 147N | |
許容慣性モーメント [モータ軸換算値] | 0.0002kg・㎡ | |
減速機仕様 | 出力軸タイプ／取付 | 平行軸／フランジ取付 |
枠番および出力軸径 | 15 mm | |
減速比 (実減速比) | 1/5 (1/5) | |
出力軸材質 | 炭素鋼 | |
モータ仕様 | モータ種類 | 標準モータ |
モータ容量 | 90W | |
相数 | 三相 | |
電圧/周波数/ 定格電流/定格回転速度 | 380V / 50Hz / 0.26A / 1300r/min 400V / 50Hz / 0.26A / 1350r/min 400V / 60Hz / 0.26A / 1550r/min 440V / 60Hz / 0.26A / 1600r/min | |
コンデンサ | - | |
保護構造 | IP20 | |
時間定格 | S1 CONT. | |
規格 | 対応規格 | 規格なし |
海外型式 | 海外型式置換え | |
質量・梱包 | 概略質量 | 3 kg |
梱包形状 | 段ボール 276×166×183 |
苏州上野机电设备有限公司销售型号：
GFM-12-50-T40W GFM-15-200-T25 GFM-12-5-T15 GFM-22-375-T60
GFM-12-60-T15 GFM-15-200-T25W GFM-12-5-T15W GFM-22-375-T60W
GFM-12-60-T15W GFM-15-240-T25 GFM-12-5-T25 GFM-22-450-T15
GFM-12-60-T25 GFM-15-240-T25W GFM-12-5-T25W GFM-22-450-T15W
GFM-12-60-T25W GFM-18-40-T90 GFM-12-5-T40 GFM-22-450-T25
GFM-12-60-T40 GFM-18-40-T90W GFM-12-5-T40W GFM-22-450-T25W
GFM-12-60-T40W GFM-18-50-T90 GFM-12-5-T60 GFM-22-450-T40
GFM-12-80-T15 GFM-18-50-T90W GFM-12-7.5-T15 GFM-22-450-T40W
GFM-12-80-T15W GFM-18-60-T90 GFM-12-7.5-T15W GFM-22-450-T60
GFM-12-80-T25 GFM-18-60-T90W GFM-12-7.5-T25 GFM-22-450-T60W
GFM-12-80-T25W GFM-18-80-T60 GFM-12-7.5-T25W GFM-22-600-T15
GFM-12-100-T15 GFM-18-80-T60W GFM-12-7.5-T40 GFM-22-600-T15W
GFM-12-100-T15W GFM-18-80-T90 GFM-12-7.5-T40W GFM-22-600-T25
GFM-12-100-T25 GFM-18-80-T90W GFM-12-7.5-T60 GFM-22-600-T25W
GFM-12-100-T25W GFM-18-100-T60 GFM-12-10-T15 GFM-22-750-T15
GFM-12-120-T15 GFM-18-100-T60W GFM-12-10-T15W GFM-22-750-T15W
GFM-12-120-T15W GFM-18-100-T90 GFM-12-10-T25 GFM-22-750-T25
GFM-12-120-T25 GFM-18-100-T90W GFM-12-10-T25W GFM-22-750-T25W
GFM-12-120-T25W GFM-18-120-T60 GFM-12-10-T40 GFM-22-900-T15
GFM-12-160-T15 GFM-18-120-T60W GFM-12-10-T40W GFM-22-900-T15W
GFM-12-160-T15W GFM-18-120-T90 GFM-12-10-T60 GFM-22-900-T25
GFM-12-200-T15 GFM-18-120-T90W GFM-12-15-T15 GFM-22-900-T25W
GFM-12-200-T15W GFM-18-160-T40 GFM-12-15-T15W GFM-28-1200-T25
GFM-12-240-T15 GFM-18-160-T40W GFM-12-15-T25 GFM-28-1200-T25W
GFM-12-240-T15W GFM-18-160-T60 GFM-12-15-T25W GFM-28-1500-T25
GFM-15-5-T60W GFM-18-160-T60W GFM-12-15-T40 GFM-28-1500-T25W
GFM-15-5-T90 GFM-18-160-T90 GFM-12-15-T40W GFM-28-1800-T25
GFM-15-5-T90W GFM-18-160-T90W GFM-12-15-T60 GFM-28-1800-T25W
GFM-15-7.5-T60W GFM-18-200-T40 GFM-12-20-T15 GFM-28-300-T90
GFM-15-7.5-T90 GFM-18-200-T40W GFM-12-20-T15W GFM-28-300-T90W
GFM-15-7.5-T90W GFM-18-200-T60 GFM-12-20-T25 GFM-28-375-T90
GFM-15-10-T60W GFM-18-200-T60W GFM-12-20-T25W GFM-28-375-T90W
GFM-15-10-T90 GFM-18-200-T90 GFM-12-20-T40 GFM-28-450-T90
GFM-15-10-T90W GFM-18-200-T90W GFM-12-20-T40W GFM-28-450-T90W
GFM-15-15-T60W GFM-18-240-T40 GFM-12-20-T60 GFM-28-600-T40
GFM-15-15-T90 GFM-18-240-T40W GFM-12-25-T15 GFM-28-600-T40W
GFM-15-15-T90W GFM-18-240-T60 GFM-12-25-T15W GFM-28-600-T60
GFM-15-20-T60W GFM-18-240-T60W GFM-12-25-T25 GFM-28-600-T60W
GFM-15-20-T90 GFM-18-240-T90 GFM-12-25-T25W GFM-28-750-T40
GFM-15-20-T90W GFM-18-240-T90W GFM-12-25-T40 GFM-28-750-T40W
GFM-15-25-T60W GFM-22-1200-T15 GFM-12-25-T40W GFM-28-750-T60
GFM-15-25-T90 GFM-22-1200-T15W GFM-12-25-T60 GFM-28-750-T60W
GFM-15-25-T90W GFM-22-1500-T15 GFM-12-30-T15 GFM-28-900-T40
GFM-15-30-T60W GFM-22-1500-T15W GFM-12-30-T15W GFM-28-900-T40W
GFM-15-30-T90 GFM-22-1800-T15 GFM-12-30-T25 GFM-28-900-T60
GFM-15-30-T90W GFM-22-1800-T15W GFM-12-30-T25W GFM-28-900-T60W
GFM-15-40-T60 GFM-22-300-T15 GFM-12-30-T40 GFM-32-1200-T40
GFM-15-40-T60W GFM-22-300-T15W GFM-12-30-T40W GFM-32-1200-T40W
GFM-15-50-T60 GFM-22-300-T25 GFM-12-30-T60 GFM-32-1200-T60
GFM-15-50-T60W GFM-22-300-T25W GFM-12-40-T15 GFM-32-1200-T60W
GFM-15-60-T60 GFM-22-300-T40 GFM-12-40-T15W GFM-32-1500-T40
GFM-15-60-T60W GFM-22-300-T40W GFM-12-40-T25 GFM-32-1500-T40W
GFM-15-80-T40 GFM-22-300-T60 GFM-12-40-T25W GFM-32-1500-T60
GFM-15-80-T40W GFM-22-300-T60W GFM-12-40-T40 GFM-32-1500-T60W
GFM-15-100-T40 GFM-22-375-T15 GFM-12-40-T40W GFM-32-1800-T40
GFM-15-100-T40W GFM-22-375-T15W GFM-12-50-T15 GFM-32-1800-T40W
GFM-15-120-T40 GFM-22-375-T25 GFM-12-50-T15W GFM-32-1800-T60
GFM-15-120-T40W GFM-22-375-T25W GFM-12-50-T25 GFM-32-1800-T60W
GFM-15-160-T25 GFM-22-375-T40 GFM-12-50-T25W GFM-32-600-T90
GFM-15-160-T25W GFM-22-375-T40W GFM-12-50-T40 GFM-32-600-T90W
GFM-40-1200-T90 GFM-32-750-T90 GFM-40-1500-T90W
GFM-40-1200-T90W GFM-32-750-T90W GFM-40-1800-T90 GFM-32-900-T90W
GFM-40-1500-T90 GFM-32-900-T90 GFM-40-1800-T90W
